Specifications

GENERAL

Frequency coverage*1
  U.S.A. Version Europe Version
Receiver 0.030–60.000MHz*2 0.030–60.000MHz*2
Transmit 1.800–1.999MHz
3.500–3.999MHz
5.255–5.405MHz*2
7.000–7.300MHz
10.100–10.150MHz
14.000–14.350MHz
18.068–18.168MHz
21.000–21.450MHz
24.890–24.990MHz
28.000–29.700MHz
50.000–54.000MHz
0.1357–0.1378MHz
1.810–1.999MHz
3.500–3.800MHz
7.000–7.200MHz
10.100–10.150MHz
14.000–14.350MHz
18.068–18.168MHz
21.000–21.450MHz
24.890–24.990MHz
28.000–29.700MHz
50.000–52.000MHz
*1 Varies according to version.
*2 Some frequency bands are not guaranteed.
Mode USB, LSB, CW, RTTY, PSK31/63, AM, FM
No. of memory channels 101 (99 regular, 2 scan edges)
Antenna connector SO-239×4 and BNC×2 (50Ω unbalanced (Tuner off))
Operating temp. range 0°C to +50°C; +32°F to +122°F
Frequency stability Less than ±0.05ppm (0°C to +50°C @ 54MHz, after warm up)
Frequency resolution 1Hz (minimum)
Power supply requirement 85–265V AC
Current drain TX: 800VA (Max. power)
RX: 130VA/120VA typ. (Max. audio/standby)
Dimensions (W×H×D,
projections not included)
425×149×435 mm; 16.73×5.87×17.13 in
Weight (approximate) 23.5 kg; 51.8 lb

TRANSMITTER

Output power SSB/CW/FM/RTTY/PSK: 5–200W
AM: 5–50W
Transverter connector (CW): More than –20dBm
Modulation system SSB : Digital P.S.N. modulation
AM : Digital low power modulation
FM : Digital phase modulation
Spurious emissions HF bands: More than 60dB,
50MHz band: More than 70dB
Carrier suppression More than 63dB
Unwanted sideband
suppression
More than 70dB
⊿TX variable range
Microphone impedance
±9.999kHz
Microphone impedance 600? (8-pin connector)

RECEIVER

Receive system Double conversion super-heterodyne system
Intermediate frequencies Main receiver: 64.455MHz/36kHz (1st/2nd)
Sub receiver: 64.555MHz/36kHz (1st/2nd)
Sensitivity (typical)
(HF: Pre-amp 1 ON, 50MHz: Pre-amp 2 ON)
SSB, CW, RTTY, PSK (BW=2.4kHz, at 10dB S/N)
0.1MHz?1.7999MHz?0.5?V
1.8MHz?29.990MHz?0.16?V
50MHz?54MHz????0.13?V

AM (BW=6kHz, at 10dB S/N)
0.1MHz?1.7999MHz?6.3?V
1.8MHz?29.990MHz?2?V
50MHz?54MHz????1?V

FM (BW=15kHz, at 12dB SINAD)
1.8MHz?29.990MHz?0.5?V (28–29.9MHz)
50MHz?54MHz?0.32?V
Squelch sensitivity SSB, CW, RTTY, PSK: Less than 5.6?V (Pre-amp: OFF)
FM: Less than 1?V (Pre-amp: OFF)
Selectivity SSB (BW=2.4kHz, sharp)?2.4kHz/-3dB?3.6kHz/-60dB
CW/RTTY/PSK (BW=500Hz, sharp)?500Hz/-3dB?700Hz/-60dB
AM(BW=6kHz)?6.0kHz/-3dB?15kHz/-60dB
FM(BW=15kHz)?12kHz/-6dB?20kHz/-60dB
Spurious and image rejection ratio More than 70dB
Audio output power More than 2.6W (10% distortion, 8? load)
RIT variable range ±9.999kHz

ANTENNA TUNER

Matching impedance
range
HF bands: 16.7? to 150? unbalanced (VSWR better than 3:1)
50MHz: 20? to 125? unbalanced (VSWR better than 2.5:1)
Minimum operating
power
HF bands: 8W,
50MHz band: 15W
Tuning accuracy VSWR 1.5:1 or less
Insertion loss Less than 1.0 dB (after tuning)

SUPPLIED ACCESSORIES

Rack mount handles
SD card
AC power cable
Spare fuses
Plugs

PANEL VIEW

Front panel view Rear panel view
